Straight Silicone Reducers

Silicone Reducer Silicone Reducer Silicone Reducer

ACE straight silicone reducers are made of reinforced and knitted polyester fabric with high-quality silicone rubber, which has excellent resistance to high or low temperatures, UV, water, ozone, oxygen and corrosion.

ACE straight silicone reducers are used for turbocharger and supercharger, intercooler, and cooling systems in industries such as commercial truck and bus, marine, agricultural and off highway vehicles, high performance racing vehicles, turbo diesel, and general manufacturing industries.

Technical Details:
Reinforcement: 3-, 4-, 5-, 6- ply polyester fabric Working Pressure: 0.3 MPa to 1.2 MPa
Temperature Range: – 60 ºC to + 180 ºC  (-76ºF ~ +356ºF) Colors: Red, blue, yellow, black, green, pink
Quality: Manufactured under the ISO 9001 quality system Remark: Silicone hose is NOT compatible with fuel or oil.
Item No. Inner Diameter Inner Diameter Length Wall Thickness
 (mm) (inch) (mm) (mm)
MTD1-3-0001 38-28mm 1 1/2″>1 1/8″ 130 3.5mm
MTD1-3-0002 38-32mm 1 1/2″>1 1/4″ 130 3.5mm
MTD1-3-0003 38-35mm 1 1/2″>1 3/8″ 130 3.5mm
MTD1-3-0004 45-38mm 1 3/4″>1 1/2″ 130 3.5mm
MTD1-3-0005 48-25mm 1 7/8″>1″ 130 3.5mm
MTD1-3-0006 48-30mm 1 7/8″>1 1/4″ 130 3.5mm
MTD1-3-0007 51-38mm 2″>1 1/2″ 130 4mm
MTD1-3-0008 51-45mm 2″>1 3/4″ 130 4mm
MTD1-3-0009 54-51mm 2 1/8″>2″ 130 4mm
MTD1-3-0010 57-51mm 2 1/4″>2″ 130 4mm
MTD1-3-0011 60-48mm 2 3/8″>1 7/8″ 130 4mm
MTD1-3-0012 60-51mm 2 3/8″>2″ 130 4mm
MTD1-3-0013 60-57mm 2 3/8″>2 1/4″ 130 4mm
MTD1-3-0014 63-51mm 2 1/2″>2″ 130 4mm
MTD1-3-0015 63-57mm 2 1/2″>2 1/4″ 130 4mm
MTD1-3-0016 70-51mm 2 3/4″>2″ 130 4mm
MTD1-3-0017 70-57mm 2 3/4″>2 1/4″ 130 4mm
MTD1-3-0018 70-63mm 2 3/4″>2 1/2″ 130 4mm
MTD1-3-0019 76-51mm 3″>2″ 130 4mm
MTD1-3-0020 76-63mm 3″>2 1/2″ 130 4.5mm
MTD1-3-0021 76-70mm 3″>2 3/4″ 130 4.5mm

The above all are typical products, special products can be made according to customers’ requirements.
